Auto GPS Car Tracker Locator Vehicle Tracking Device GPS-303 Negotiable

Product Details

Description

This tracker is a new product based on the GSM / GPRS network and GPS satellite positioning system, which set multiple functions of security, positioning, monitoring surveillance, emergency alarms and tracking in its entirety. It can track and monitor remote target by SMS or internet.

Vehicle GPS tracker with built-in GPS/GSM antennas ,Anti-theft GPS car tracker.

2. Features

Built-in GSM, GPS antenna, Waterproof ,compact, elegant appearance.

Support GPS and LBS (Location based service) double tracking solutions.

Support SMS/GPRS/Internet Network data transmission.

Support configure the settings remotely.

Set multiple functions of security, tracking, monitoring surveillance, emergency alarms and management in its entirety.

3. Main Function Description

1.For all models vehicles(12-24V)

2.Location based service(LBS) + GPS double tracking solution

3.GPS blind spot alert

4.multi power-saving mode :

Sleep by time / shock sensor

deep sleep

awake at specific time

5.Save GPRS traffic mode(Money save mode)

6.Anti-theft gsm alarms:

Movement alarm

Geo-fence alarm

Over speed alarm

ext.power off alarm

low battery alarm

7.Alarms under ARM State: ACC/Shock alarms

8.Remotey shutdown engine

9.Support MiroSD

10.Built-in memory for 16,000 positions

11.Built-in 350 mA polymer battery

12.SMS tracking on cell phone with google map link

13.Absolute street address by SMS

14.Web server, free PC tracking soft, Mobile phone APP

Application:For vehicles,cars,motorcycle,fleet management.

4.Specification:

Content

Specification

DIM

9.6x5.3x1.6cm

Weight

70g

Network

GSM/GPRS

Band

850/900/1800/1900Mhz

GPS sensitivity

-159dBm

GPS accuracy

5M

GPS start time

Cold status 45s

Warm status 35s

 Hot status 1s

Car power supply

12 V - 24 V

Back up battery

Chargeable 3.7V 350mAh Li-ion battery

Storage Temp

-40°C to +85°C

Operation Temp

-20°C to +65°C

Humidity

5%--95% non-condensing

5.Hardware Description


Wiring Diagram of gps tracker 303H:

Find the 12 PIN harness and insert it into the corresponding holes of the products, and connect the wires with the car circuit showing below:

033_zps6cfa76f0

  Package Content of gps tracker 303H:

1pc * GPS Main Unit GPS303H

1pc * 12Pin harness 1pc * Screwdriver 1pc * User manual 1PC* External microphone 1PC* relays

Key Features

GPS type:GPS Tracker

Screen Size:Under 2 Inches

Battery Life:30 Hours & Up

Gps Module:Yes

Item Size:9.6x5.3x1.6cm

Voltage:24V

Special Feature:Internet Connected

Out Power:12-24V

Model Name:GPS303H

DIM:9.6x5.3x1.6cm

Weight:70g

Network:GSM/GPRS

Band:850/900/1800/1900Mhz

GPS sensitivity:-159dBm

GPS accuracy:5m

GPS start time:Cold status 45s, Warm status 35s, Hot status 1s

Car power supply:12 V - 24 V

Back up battery:Chargeable 3.7V 350mAh Li-ion battery

Storage Temp:-40 to +85 degree

Operation Temp:-20 to +65 degree

Humidity:5%--95% non-condensing

Specifications

SKU: GE779OT1AZ8EINAFAMZ

Product Line: Kachisonic investment ng ltd

Model: GPS-303

Production Country: China

Size (L x W x H cm): 12 x 3 x 10

Weight (kg): 0.2

Color: white

Main Material: PVC

NAFDAC Reg. Number: N/A
